The DL 126 recessed fitting impresses with its low height and it is therefore ideal for use with low installation depths. The six long-life SMD LEDs with a total power output of 3W ensure that you have the necessary level of illumination. The recessed fitting is available with a shutter coloured white, chrome and brushed metal. A suitable 12V direct current power supply is needed for operation. This luminaire contains built-in warm-white LED lamps.

Tehnilised andmed

Width	65 mm
IP Code	IP20
Lumen	170 lm
Colour temperature	3000 K
CRI	80-89
Rated life time	Rated life time L70/B50 at 25 °C h
Safety class	III
Lamp type	LED not exchangeable
Hämardamine	No
CUT OUT DIAMETER IN CM	5.7
CUT OUT DEPTH IN CM	1.4
CUT OUT FORM IN CM	round
PRODUCT DIAMETER IN CM	6.5
PRODUCT WIDTH IN CM	6.5
PRODUCT LENGTH IN CM	6.5
LIFE TIME IN H	60000
BEAM ANGLE	90
EEK	contains Lightsources of EEC G
RATED PRIMARY VOLTAGE	12V DC
Built-in height/depth	14 mm
Built-in width	57 mm
Colour housing	Chrome
Surface protection	Lacquered
Material housing	Aluminium
Tehnilised failid	CE-Declaration Mounting instruction
Kategooriad	Ceiling lights, Indoor, LED, Recessed
Sildid	LED-Downlight
