HIGHBAY V 330, 100/120/170/200W 840 90°

normal
Dimensioned drawing
Product picture back view
Product picture bottom view
Product picture detailed view
Product picture front view
Product picture sloping
Product picture top view
Product picture view from the left side
Product picture view from the right side
Uus
  • normal
  • Dimensioned drawing
  • Product picture back view
  • Product picture bottom view
  • Product picture detailed view
  • Product picture front view
  • Product picture sloping
  • Product picture top view
  • Product picture view from the left side
  • Product picture view from the right side

Discover our new technical product range: SLVtec. With state-of-the-art LED technology, we offer energy-efficient and functional lighting solutions for indoor and outdoor use. From wet room lights to high-bay spotlights – our high-quality products impress with functionality and a fair price-performance ratio. This includes the HIGHBAY V pendant light, whose light intensity can be adjusted up to 32000lm via dip switches. With its protection code IP65, it is optimally protected against dirt and moisture. At the same time, it impresses with its modern design and a service life of L70/B50@50,000h. Decide in favour of SLVtec today.

Tehnilised andmed

Width 330 mm
IP Code IP65
Wattage 200 W
Lumen 32000
Colour temperature 4000 K
CRI 80-89
Diameter 330 mm
Safety class
Lamp type LED not exchangeable
Hämardamine No
PRODUCT DIAMETER IN CM 33
PRODUCT WIDTH IN CM 33
PRODUCT LENGTH IN CM 33
LIFE TIME IN H 50000
BEAM ANGLE 90
RATED SECONDARY IN MA/V 830mA
RATED PRIMARY VOLTAGE 220-240V ~50/60Hz
Length 330 mm
Height/depth 119 mm
Luminaire efficacy 160.00
Suitable for lamp power 200 W
Impact resistance class IK08
Light outlet Direct
Material cover Other
Colour housing Black
Material housing Aluminium
Tehnilised failid Mounting instruction
Product data sheet
Declaration warranty
Kategooriad Ceiling lights, Indoor
