Tiltable high-voltage recessed fitting from the HORN series. The lamp is installed set to the rear in this luminaire which is made out of steel. This design creates a special appearance while effectively reducing glare. Multi-lamp and low-voltage versions of this series are available.

Tehnilised andmed

Width	105 mm
IP Code	IP20
Dimming technology	Dimming mains voltage modulation
Wattage	50 W
Safety class	II
Lamp type	LED exchangeable
CUT OUT DIAMETER IN CM	9.7
CUT OUT DEPTH IN CM	13
CUT OUT FORM IN CM	round
PRODUCT DIAMETER IN CM	10.5
PRODUCT WIDTH IN CM	10.5
PRODUCT LENGTH IN CM	10.5
RATED PRIMARY VOLTAGE	230V ~50Hz
Built-in height/depth	130 mm
Built-in width	97 mm
Suitable for lamp power	50 W
Light outlet	Direct
Colour housing	Black
Surface protection	Lacquered
Material housing	Aluminium
Tehnilised failid	CE-Declaration Mounting instruction
Kategooriad	Ceiling lights, Indoor, Other light source, Recessed
Sildid	230 voltage Ceiling recessed luminaire, HV-Downlight
