The innovative PATTA I recessed fitting is suitable for ceiling thicknesses of up to 25 mm. Rated IP65 it can be used outdoors or in damp areas. This set is available in matt black, matt white, or brushed aluminium as well as in round or square form. Equipped with a powerful, warm white premium COB LED in a rigid mount, as well as the dimmable LED driver included in the scope of supply, the set can be used in any lighting situation. The electrical connection is made directly to the 230V mains supply.

Tehnilised andmed

Width	80 mm
IP Code	IP20
Dimming technology	Dimming phase cut-off (trailing edge)
Wattage	11 W
Lumen	910 lm
Colour temperature	3000 K
CRI	80-89
Rated life time	Rated life time L70/B50 at 25 °C h
Safety class	II
Lamp type	LED not exchangeable
CUT OUT DIAMETER IN CM	6
CUT OUT DEPTH IN CM	6
CUT OUT FORM IN CM	round
PRODUCT WIDTH IN CM	8
PRODUCT LENGTH IN CM	8
LIFE TIME IN H	40000
BEAM ANGLE	38
EEK	contains Lightsources of EEC E
RATED SECONDARY IN MA/V	500mA
RATED PRIMARY VOLTAGE	220-240V ~50/60Hz
Luminaire efficacy	82.73 lm/W
Built-in height/depth	60 mm
Built-in width	60 mm
Suitable for lamp power	11 W
Colour housing	White
Surface protection	Lacquered
Material housing	Aluminium
Tehnilised failid	CE-Declaration Light Distribution Curve Mounting instruction
Kategooriad	Ceiling lights, LED, Outdoor, Recessed
Sildid	LED-Downlight
